VA Series Rubber Cup Mounts are high quality cost efficient and uniquely constructed industrial mounts that provide excellent protection against severe vibration and noises. VA uses the rubber profile in shear and compression for normal speeds of approximately 1500RPM. The VA provides a degree of Isolation of 75-85%. All models are fitted with lock washer (fail-safe design).
Compressors
Combustion engines
Marine and Industrial generators
Fans
Transformers
Pumps
Wide load Range (30-3000Kg)
Corrosion protected
Stronger base plate withstands high shock loads
Resilient stop in each model, making VA ideal for use in mobile and marine applications
Top plate is dome shaped to guard against contamination
High Grade Neoprene rubber for industrial application
ANDRE_VA Series.pdf
ANDRE_RubberMounts_VA Series - Submittal.pdf
MODEL | MAX LOAD (KG) | LOAD RANGE (KG) |
|---|---|---|
| VA-65-A | 75 | 30-75 |
| VA-65-B | 120 | 80-120 |
| VA-65-C | 140 | 100-140 |
| VA-90-A | 200 | 100-200 |
| VA-90-B | 350 | 160-350 |
| VA-90-C | 450 | 240-450 |
| VA-110-A | 360 | 200-360 |
| VA-110-B | 500 | 300-500 |
| VA-110-C | 700 | 420-700 |
| VA-150-A | 900 | 600-900 |
| VA-150-B | 1300 | 900-1300 |
| VA-150-C | 2000 | 1200-2000 |
| VA-180-A | 2000 | 1600-2000 |
| VA-180-B | 2400 | 1900-2400 |
| VA-180-C | 3000 | 2400-3000 |
