RMD Series are elastomeric mounts which provide effective vibration control for all types of rotating machines. The RMD Series double deflection rubber in shear mounts are color coded for identification of loading capacity and prevents installation errors. The RMD Series have ribbed and non-skid bases. No bolting of anchor bolts is required for machines that have no lateral motion.
Air handling units
Compressors
Fans
Pumps
HVAC Equipments
Generators
Transformers
Anti-skid top and bottom surfaces
Mounting holes provided as standard
Embedded steel plates for uniform loading.
Oil and water resistant
High deflection
Color coded for easy identification
Material: Polymer compound
ANDRE_RubberMounts_RMD.pdf
ANDRE_RUBBERMOUNTS_RMD- Submittal.pdf
MODEL | Max Load (lbs) | Deflection (inches) | Color |
|---|---|---|---|
| RMD-A-1 | 30 | 0.35 | Blue |
| RMD-A-2 | 40 | 0.35 | Red |
| RMD-A-3 | 70 | 0.35 | Green |
| RMD-A-4 | 115 | 0.35 | Black |
| RMD-B-1 | 130 | 0.40 | Blue |
| RMD-B-2 | 165 | 0.40 | Red |
| RMD-B-3 | 235 | 0.40 | Green |
| RMD-B-4 | 375 | 0.40 | Black |
| RMD-C-1 | 200 | 0.50 | Blue |
| RMD-C-2 | 300 | 0.50 | Red |
| RMD-C-3 | 400 | 0.50 | Green |
| RMD-C-4 | 500 | 0.50 | Black |
| RMD-D-1 | 750 | 0.50 | Blue |
| RMD-D-2 | 1000 | 0.50 | Red |
| RMD-D-3 | 1500 | 0.50 | Green |
| RMD-D-4 | 2200 | 0.50 | Black |
| RMD-D-5 | 3300 | 0.50 | Black (White Dot) |
