NHD Series Hangers are neoprene elements housed in sturdy steel brackets. The element includes top and bottom steel plates for uniform load distribution. All elements are color coded for easy identification. The element incorporates a projected collar to prevent metal to metal contact between the rod and bracket. The NHD series hangers are used for hanging machines such as fan coil units, fans etc.
Fan Coil Units
Air Handling Units
Fans
Pipes
Ducts
Steel Plates are embedded in the element for uniform loading
Element is oil and water resistant
ANDRE_RubberHangers_NHD - Submittal.pdf
ANDRE_RubberHangers_NHD.pdf
MODEL | MAX LOAD (LBS) | DEFLECTION (INCHES) | COLOR |
|---|---|---|---|
| NHD-1-A | 30 | 0.4 | Blue |
| NHD-1-B | 40 | 0.4 | Red |
| NHD-1-C | 70 | 0.4 | Green |
| NHD-1-D | 115 | 0.4 | Black |
| NHD-2-A | 165 | 0.4 | Blue |
| NHD-2-B | 235 | 0.4 | Red |
| NHD-2-C | 375 | 0.4 | Green |
| NHD-2-D | 545 | 0.4 | Black |
| NHD-3-C | 745 | 0.4 | Green |
| NHD-3-D | 1245 | 0.4 | Black |
| NHD-4-B | 2240 | 0.4 | Red |
| NHD-4-C | 3000 | 0.4 | Green |
| NHD-4-D | 4000 | 0.4 | Black |
